| Stroke (X x Y x Z) | 250 x 200 x 200 mm (10 x 8 x 8”) |
| Minimum readout | 0.1 µm |
| Maximum workpiece weight | 15 kg (up to 5 kg accuracy guaranteed) |
| Measuring uncertainty | XY MPEE1: 2+8L/1000 µm |
| Z measurement uncertainty | Z MPEE1: 3+L/50 µm |
| Camera | 1/3-in. 3CCD color Progressive scan (B/W optional) |
| Working distance | 73.5 mm (63 mm with LAF) |
| Auto focus | Vision AF and optional Laser AF |
| Power source | 100-240 V, 50/60 Hz |
| Power consumption | 5-2.5 A |
| Dimensions & weight (W x D x H) | 565 x 690 x 740 mm (minimum height), 72 kg |
