Đồng Hồ Điện Tử Series 543- Standard Type

Thương hiệu: Mitutoyo | Xuất xứ: Nhật Bản

• The ABS (absolute) sensor restores the last origin position automatically
when the indicator is turned on.
• Battery life of approx. 7,000 hours in continuous use has been achieved with onlyone battery.
• Equipped with a data output port that enables incorporation into measurement networking
and statistical process control systems.

Thông số kỹ thuật

Accuracy: Refer to the list of specifications (excluding quantizing error)
Resolution:
0.01mm type 0.01mm
0.001mm type 0.01mm/0.001mm
.0005″/0.01mm type .0005″/0.01mm
.00005” /0.001mm type .0005 ”/.0001”/.00005 ” / 0.01mm/0.001mm
Display: 6-digit LCD and sign
Scale type: ABSOLUTE electrostatic linear encoder
Max. response speed: Unlimited (Measurement by scanning cannot be performed)
Measuring force: Refer to the list of specifications
Stem dia.: 8mm (ISO/JIS type) or 3/8”(ANSI/AGD type)
Battery: SR44 (1 pc.), 938882 for initial
operational checks (standard accessory)
Battery life: Approx. 7,000 hours of continuous use
Dust/Water protection level: IP42
